Model
SWT-NS630A

Item specifics

Certificate
CE, ISO9001
Packing Material
1 Set
MOQ
Plywood Box

Review

Description

product poster
Detail Information
Model
SWT-NS630A
Input voltage
230V
Frequency
50 / 60Hz
Extruding power
1150W
Hot air power
1600W
Welding rod heater power
800W
Air temperature
20 - 620 ℃
Extruding Temperature
200 - 380 ℃
Extruding volume
4 Kg/h
Welding rod diameter
φ4 - 5 mm
Weight
10.5kg
Driving motor
EIBENSTOCKC
Materials thickness
1-10 mm
Series Oe Ddoducts
Hand-held extrusion welders are usually used to weld HDPE, PP, PVDF, and other thermoplastic materials in projects like plastic water tank manufactured, plastic pipes and plastic sheets connection, etc.

Ergonomic design with comfortable grip handle, a multifunctional display screen with temperature and air volume adjustable, and simple operation are the main feature of MM-Tech extrusion welder.
Application
